Diamond Dowel

Tapered plate dowels for formed construction joints.

The industry standard for construction joints, the Diamond Dowel® System achieves superior joint stability measurements of 0.01 in (25 mm) and delivers reliable, maintenance-free and serviceable concrete flatwork. With the proven Diamond Dowel® System you can optimize materials, reduce labor costs, improve worker safety and minimize joint spalling and random cracking.

Recommended for formed construction joints in:

• Concrete slabs on grade
• Concrete pavement
• Concrete flatwork exposed to pedestrian traffic

With the proven Diamond Dowel® System, you provide the joint stability, positive load transfer and continuity of surface profile your projects demand. The Diamond Dowel® System consists of the tapered plate dowel, sleeve and installation template. The Diamond Dowel® tapered plates are available in three sizes (depending on the loads, wheel type and repetition):

• 1/4” (6mm) – typically used in 4”- 7” slab depths
• 3/8” (10 mm) – typically used in 7”- 9” slab depths
• 3/4” (20 mm) – typically used in 9” plus slab depth

 Plates are manufactured from steel certified to meet ASTM A36 (1/4” and 3/8”) or ASTM A108 (3/4”)
